  16 M6 SWITCHES SERIES  (Made in Taiwan)
  Accessories

Category Shape Type No. Function. Specifications
Incandescent
Lamp
L-06
L-14
L-28
6V AC / DC 200mA
14V AC / DC 80mA
28V AC / DC 40mA
LED Lamp L-06E
L-12E
L-24E
Operating Voltage   Color :
Red (R)

Green (G)

Yellow (Y)
White (W)
Blue (B)
6V DC 25mA
12V DC 25mA
24V DC 25mA
Fill in the color code in
Neon Lamp L-110
L-220
Operating Voltage   Color :
Red (R)

Green (G)
110V AC 1.2mA
220V AC 1.2mA
Fill in the color code in
Protection Cap M-261 For round and square head push buttons
M-262 For rectangular
head push buttons

Dust-Proof
Cover
M-270 For round head push buttons
M-271 For square head push buttons
M-272 For rectangular head push buttons
Terminal
Cover
M-232 protection contacts against touching
Plastic Covered Key
M-162
Metal Threaded Ring M-029
Mounting Wrench M-030 Used for tightening the nut.
Lens
Removing
M-170 Used for replacing the color lens.
Lamp
Extractor
M-230 Used for replacing the lamp.
Color Lens M-218A ◎ Fill in the color code in

Color : R. G. Y. O. W. B.
  Red (R). Green (G). Yellow (Y).
Orange (O). White (W). Blue (B).
M-218B
M-218C
M-218D Opaque Color: R. G. Y.
M-218E Transparent Color: R. G. Y.
Marking
Plate
M-217A ◎ Fill in the marking in

Markings : ON. OFF. STAR. STOP. UP. DOWN.
FWD. REV. AUTO. MAN. POWER.
RESET. ↑ ↓ ← →


M-217B
M-217C
